USB OPT64

Yamutec® USB 64-fold optocoupler module

With our optocoupler module you are perfectly equipped for large projects. Capture signals from up to 64 sources safely and at high speed with our yamutec® USB optocoupler module. Through the galvanic isolation of the signal circuit from the control circuit, you perfectly protect your computer system and personnel. Optocoupler modules are therefore very suitable for medical technology to protect patients from overvoltages.

The 64 optocoupler inputs work in a voltage range of 3V to 30V. In addition, our modules take into account the standards and regulations EMC and RoHS. This means that the yamutec® USB 64-fold optocoupler module is also available Building automation, process and environmental technology very versatile.

Your advantages with the yamutec® USB 64-fold optocoupler module

The 64 inputs of our USB module support your system in signal acquisition with important properties. It is possible for you high switching performance to realize and fast input pulses reliably recorded over longer periods of time. The galvanic isolation also prevents mechanical wear, what a thing long service life with constant performance ensures. In addition, the galvanic isolation of the Signal and control circuits have different voltage potentials. In addition, the optocoupler protects your valuable control technology from the consequences of overvoltages. The Insensitivity to shock and vibration create more stability in the control and regulation loop.

Further product details about our hybrid modules

If you want to connect several yamutec® 64-fold optocouplers with USB ports of the same series, it is possible using the Coding switch on board Specify an identification number for each individual optocoupler module. Recesses in the aluminum housing are provided for mounting the module. You can mount the USB module either on a wall or on a top-hat rail. Built-in control LEDs inform you about the status of the 64 entrances.

In addition, they have yamutec® USB optocoupler modules with 64 inputs about the Human Interface Device (HID) procedure and do not require driver installation. This enables more reliable and faster communication compared to standard modules. You save time with the help of Plug and Play technology.

Where can our optocouplers be used?

Due to the product features described above, our optocouplers are suitable for the following purposes:

• for medical and safety technology to ensure surge protection
• when controlling circuit parts that have different voltage potentials - for example interface and network cards
• to comply with standards in the field of high-speed communication
• Automation and safety technology with high switching times and fast information transmission
