USB modules

USB relay modules and
I/O modules, also with integrated
Logic technology
Run autonomously. Deploy flexibly. Without a control PC.
With integrated AI support
PRODUCT CATEGORY
USB Module
Relay, optocoupler and hybrid modules

Our Yamutec® USB modules are designed for reliable control, switching and data acquisition tasks in industrial, test bench and laboratory applications.

Depending on the model, relay outputs, galvanically isolated optocoupler inputs, or combined hybrid solutions are available. The modules are connected directly via USB and are thanks to USB HID Ready to use immediately without additional driver installation.

Many USB modules also optionally come with integrated Yamutec® Logic available and can therefore execute switching, logic and sequence controls directly in the module.

Connect. Control. Automate.

Our Yamutec® USB modules can be easily integrated into existing applications and are suitable for control, monitoring and automation tasks.

For software development, the following is available to you: YMLib API available. This allows the USB modules to be used with, among other things, VB6, VB.NET, C#, .NET 6, Python and LabVIEW can be individually integrated into your own applications.

With Yamutec® Logic It goes one step further: The control logic is graphically represented in Yamutec® Studio 2027 created, transferred directly to the module and then executed autonomously.

This means that a permanent connection to a control PC is not required for program execution.

MODULE SELECTION
Which module suits your needs? Application?
Depending on the task, relay, optocoupler, and hybrid modules perform different functions. Yamutec® Logic The control logic is executed directly in the module.

Control & switch

Ideal if switching operations, time functions or recurring processes are to be executed independently directly in the module.

Typical applications

Relay control · Timers · Sequences · Automatic switching processes

Capture & analyze

For applications where digital input signals need to be monitored, linked, counted, or evaluated over time.

Typical applications

Condition monitoring · Pulse counting · Signal filtering · Alarm conditions

Capture & switch

Capture input signals, with Logic Evaluate the data and directly generate output actions from it – all within a single module.

Typical applications

Sensor → Logic → Relays · Test benches · Machine peripherals · Autonomous controls
PRODUCT OVERVIEW
Our USB modules
High-performance I/O modules – optionally with integrated Yamutec® Logic Function.
Relaismodul

USB relay modules

About the product details:

4 relay modules

USB REL4_8A Look at the details

16 relay modules · Logic

USB REL16 Look at the details
USB REL16_3A Look at the details

32 relay modules · Logic

USB REL32 Look at the details
USB REL32_3A Look at the details

64 relay modules · Logic

USB REL64 Look at the details
USB REL64_3A Look at the details

Optokopplermodul

USB optocoupler modules

About the product details:

16 optocoupler modules · Logic

USB OPT16 Look at the details

32 optocoupler modules · Logic

USB OPT32 Look at the details

64 optocoupler modules · Logic

USB OPT64 Look at the details

Hybridmodul

USB hybrid modules

About the product details:

8 hybrid modules · Logic

USB HYBRID 8 Look at the details
USB HYBRID 8_3A Look at the details

16 hybrid modules · Logic

USB HYBRID 16 Look at the details
USB HYBRID 16_3A Look at the details

32 hybrid modules · Logic

USB HYBRID 32 Look at the details
USB HYBRID 32_3A Look at the details

PRODUCT DETAILS
productcharacteristics

✓
Operate up to 7 modules simultaneously
Internal identification via on-board coding switches.

✓
Plug & Play
Simply plug it in and use it.

✓
Individually configurable timeout function
For greater security in the event of communication errors.

✓
No driver installation required
Easy integration via USB HID.

✓
Optional Yamutec® Logic function
Execute control processes directly in the module – without a permanent PC connection.

✓
Robust aluminum housing
Suitable for DIN rail and wall mounting.

✓
Galvanic isolation of inputs and outputs
For high security and interference immunity.

✓
EMC and RoHS compliant
For reliable industrial use.

✓
Status and control LEDs
Quickly and directly identify operating states.

✓
Graphical programming with AI support
Create, simulate and develop control sequences with Yamutec® Studio 2027 using the integrated AI assistant.
HIGHLIGHTS
Therefore USB modules

Plug & Play & flexible integration

Thanks to USB HID Our USB modules require no additional driver installation. Simply plug them in and use them immediately.

Multiple modules can be operated simultaneously on one system. About the On-board coding switch Each module can be assigned a unique internal identifier.

Safe operation with timeout

The integrated Timeout function monitors the communication between the control PC and the module.

In the event of a communication or software error, a defined switching state can be automatically established. The timeout can be set. Configure individually and thus increases operational reliability.

Galvanic isolation & protection

The optocoupler inputs ensure a galvanic isolation between input signals and control electronics.

This provides better protection for the system against interference, potential differences and unwanted voltage influences – ideal for reliable use in industrial applications.
